Willoughby Replacement for American Standard Neolo 2531.016 & 2530.016

• Spud | Rear
• Brand Name | Willoughby
• Country of Origin | USA

Model# ETWS-1490-FM-BS-1.6-RPF-A52531 replacement for American Standard Neolo, Fixture is fabricated from 14 GA, Type 304 stainless steel. The construction is an all welded, with exposed stainless surfaces polished to a #4 satin finish. Standard toilet includes: elongated toilet bowl with contoured seat, integral crevice-free selfdraining flushing rim with positive afterfill and fully enclosed 3” O.D. trap which maintains a minimum 2” seal and pass a 2-5/8” ball. Toilet is siphon jet type which requires 35 psi minimum flushing pressure. Fixture can withstand loadings up to 2,000 lbs. with no measurable deflection and loadings up to 5,000 lbs. with no permanent damage. Anchoring is through the front and through the floor (anchoring hardware provided by others). Back spud unit requires chase area for installation and maintenance.

Note: For 1.6 gallon flush, unit will pass a 2-1/8” ball.
